Kingston KC3000 PCIe 4.0 x4 NVMe M.2 2280 SSD (512GB / 1024GB / 2048GB / 4096GB) - Read/Write speeds up to 7,000MB/s, Low profile graphene aluminum heat spreader
Kingston KC3000 PCIe 4.0 x4 NVMe M.2 2280 SSD (512GB / 1024GB / 2048GB / 4096GB) - Read/Write speeds up to 7,000MB/s, Low profile graphene aluminum heat spreader
Couldn't load pickup availability
KC3000 PCIe 4.0 NVMe M.2 SSD
High-Performance Storage for Desktop and Laptop PCs
Kingston KC3000 PCIe 4.0 NVMe M.2 SSD delivers next-level performance using the latest Gen 4x4 NVMe controller and 3D TLC NAND. Upgrade the storage and reliability of your system to keep up with demanding workloads and experience better performance with software applications such as 3D rendering and 4K+ content creation. With formidable speeds up to 7,000MB/s read/write, it ensures improved workflow in high-performance desktop and laptop PCs making it ideal for power users who require the fastest speeds on the market.
The compact M.2 2280 design fits seamlessly into motherboards and gives greater flexibility where high-power users appreciate responsiveness and superior loading times.
Full capacities available from 512GB–4096GB to meet your data storage requirements.
Key Features
PCIe 4.0 NVMe Technology
Master intensive applications with speeds up to 7,000/7,000MB/s read/write.
Store more
Upgrade and manage storage with full capacities up to 4096GB.
Greater flexibility
Compact M.2 design fits easily into small-form-factor (SFF) systems, desktops and laptop PCs.
Low profile graphene aluminum heat spreader
Exceptional thermal dissipation keeps your drive cool with maximum performance.
Specifications
| Form factor | M.2 2280 |
| Interface | PCIe 4.0 x4 NVMe |
| Capacities | 512GB, 1024GB, 2048GB, 4096GB |
| Controller | Phison E18 |
| NAND |
3D TLC |
| DRAM Cache | Yes |
| Sequential read/write |
512GB – 7,000/3,900MB/s 1024GB – 7,000/6,000MB/s 2048GB – 7,000/7,000MB/s 4096GB – 7,000/7,000MB/s |
| Random 4K read/write |
512GB – up to 450,000/900,000 IOPS 1024GB – up to 900,000/1,000,000 IOPS 2048GB – up to 1,000,000/1,000,000 IOPS 4096GB – up to 1,000,000/1,000,000 IOPS |
| Total Bytes Written (TBW) |
512GB – 400TBW 1024GB – 800TBW 2048GB – 1.6PBW 4096GB – 3.2PBW |
| Power consumption |
512GB – 50mW idle / 0.34W avg / 2.7W (MAX) read / 4.1W (MAX) write 1024GB – 50mW idle / 0.33W avg / 2.8W (MAX) read / 6.3W (MAX) write 2048GB – 50mW idle / 0.36W avg / 2.8W (MAX) read / 9.9W (MAX) write 4096GB – 50mW idle / 0.36W avg / 2.7W (MAX) read / 10.2W (MAX) write |
| Storage temperature | -40°C~85°C |
| Operating temperature | 0°C~70°C |
| Dimensions |
80mm x 22mm x 2.21mm (512GB - 1024GB) 80mm x 22mm x 3.5mm (2048GB - 4096GB) |
| Weight |
512GB - 1024GB – 7g 2048GB - 4096GB – 9.7g |
| Vibration operating | 2.17G peak (7-800Hz) |
| Vibration non-operating | 20G Peak (20-1000Hz) |
| MTBF | 2,000,000 hours |
| Warranty/support | Limited 5-year warranty with free technical support |
| Total Bytes Written (TBW) | 250GB – 80TB 500GB – 160TB 1TB – 320TB 2TB – 640TB 4TB – 1280TB |
This SSD is designed for use in desktop and notebook computer workloads and is not intended for server environments.
1. Based on “out-of-box performance” using a PCIe 4.0 motherboard. Speed may vary due to host hardware, software and usage.
2. Some of the listed capacity on a Flash storage device is used for formatting and other functions and thus is not available for data storage. As such, the actual available capacity for data storage is less than what is listed on the products. For more information, go to Kingston's Flash Memory Guide.
3. Total Bytes Written (TBW) is derived from the JEDEC Client Workload (JESD219A).
4. Limited warranty based on 5 years or “Percentage Used” which can be found using the Kingston SSD Manager (kingston.com/ssdmanager). For NVMe SSDs, a new unused product will show a Percentage Used value of 0, whereas a product that reaches its warranty limit will show a Percentage Used value of greater than or equal to one hundred (100). See kingston.com/wa for details.
