KIOXIA
KIOXIA EXCERIA PLUS G3 M.2 2280 NVMe 1.4 PCIe 4.0 SSD (1TB / 2TB) - Read/Write Speed up to 5000/3900 MB/s, Internal Drive for Notebook/Laptop, Desktop PC, Gaming, Gamers and Video Editors
KIOXIA EXCERIA PLUS G3 M.2 2280 NVMe 1.4 PCIe 4.0 SSD (1TB / 2TB) - Read/Write Speed up to 5000/3900 MB/s, Internal Drive for Notebook/Laptop, Desktop PC, Gaming, Gamers and Video Editors
Couldn't load pickup availability
EXCERIA PLUS G3
The KIOXIA EXCERIA PLUS G3 SSD series features a powerful PCIe® 4.0 interface and delivers improved performance for gamers and video editors. With up to 2TB of capacity, this M.2 2280 single-sided series is excellent for mainstream desktops and notebooks that support the latest PCIe® 4.0 standard.
- Capacity: 1TB / 2TB
- Max Sequential Read / Write Speed: 5,000 / 3,900 MB/s
- Max Random Read / Write Speed:
770,000 / 950,000 IOPS (1TB) / 680,000 / 950,000 IOPS (2TB)
- Usage: Client desktops and laptops
Features
- BiCS FLASH™
- NVMe™ 1.4 Technology
- M.2 2280 Form Factor
- PCIe® Gen4 x4
- SSD Utility Management Software
Welcome to the World of PCIe® 4.0
Designed to deliver an enhanced PC experience, the EXCERIA PLUS G3 SSD series is compatible with PCIe® 4.0 and delivers exceptional transfer speeds of up to 5,000 MB/s for sequential reads and 3,900 MB/s for sequential writes. Whether you are gaming or video editing, this new series will provide the performance needed.
Storage Slimmed Down
Featuring a space-saving, single-sided M.2 2280 form factor, the EXCERIA PLUS G3 SSD series is compatible with a wider range of devices. These compact SSDs plug directly into the motherboard, removing cable clutter for a sleeker and an easy system upgrade.
Speed Ahead with PCIe® 4.0
The EXCERIA PLUS G3 SSD series delivers improved performance without cutting corners. Supporting PCIe® 4.0 and NVMe™ 1.4, these SSDs take mainstream to the next level and offer an upgraded computing experience for gamers and video editors.
Cutting-Edge 3D Flash Memory
Each EXCERIA SSD is built with BiCS FLASH™ and a vertically stacked cell structure, delivering a cutting edge storage experience.
SSD Utility Management Software
The SSD Utility management software was designed to help your KIOXIA drive thrive and lets you be in control of maintenance, monitoring and more!
We highly recommend you install and update to the latest version to maximize your drive’s performance and check its Percentage Life Left using the health gauge.
EXCERIA PLUS G3 SSD Product Specifications
| Capacity / Dimensions | |
|---|---|
|
Capacity: 1TB, 2TB |
Form Factor: M.2 Type 2280-S4-M |
|
Interface: PCI Express® Base Specification Revision 4.0 (PCIe®) |
Flash Memory type: BiCS FLASH™ TLC |
|
Interface Maximum Speed: 64 GT/s (PCIe® Gen4x4) |
Dimension (Max: LxWxH): 80.15 x 22.15 x 2.63 mm |
|
Interface Protocol: NVM Express™ Base Specification 1.4 |
Weight: 1TB: 7.0 g (typ.) 2TB: 7.4 g (typ.) |
| Performance | |
|
Max Sequential Read Speed: 5,000 MB/s |
Max Sequential Write Speed: 3,900 MB/s |
|
Max Random Read Speed: 1TB: 770,000 IOPS 2TB: 680,000 IOPS |
Max Random Write Speed: 950,000 IOPS |
|
Endurance: TBW 1TB: 600 TB 2TB: 1,200 TB |
MTTF: 1.5 million hours |
| Operating environment / Protection performance | |
|
Operating Temperature: 0 ℃ (Ta) to 85 ℃ (Tc) |
Storage Temperature: -40 ℃ to 85 ℃ |
|
Certification: RoHS compliant |
Shock Resistance: 9.806 km/s {1,000 G} 0.5 ms half sine wave |
|
Vibration: 196 m/s {20 G} Peak, 10~2,000 Hz, (20 min / Axis) x 3 Axis |
Supply Voltage: 3.3 V ±5 % |
|
Power Consumption: PS3: 50 mW (typ.) PS4: 5 mW (typ.) |
Power Consumption (Active): 1TB: 4.9 W (typ.) 2TB: 5.3 W (typ.) |
| Compatibility | |
|
Connector Type: M.2 M key Socket |
Target Applications: Client desktops and laptops |
| Others | |
|
Services and Support: Up to 5-year manufacturer's warranty* |
Performance Optimization: TRIM, Idle Time Garbage Collection, Host Memory Buffer |
| Product Info | |
|
1TB PN: LSD10Z001TG8 EAN: 4582563857872 |
2TB PN: LSD10Z002TG8 EAN: 4582563857889 |
