LIAN LI UNI FAN SL140 2 Fans Pack with Controller (ARGB 140mm LED PWM, Daisy-Chain) - Black / White
LIAN LI UNI FAN SL140 2 Fans Pack with Controller (ARGB 140mm LED PWM, Daisy-Chain) - Black / White
Couldn't load pickup availability
UNI FAN SL140
Revolutionary fan with modular design, interlocking fan that can be linked up and operate with a fan and RGB cable. The included UNI HUB contains 4 designated UNI FAN ports. Each port can connects to a cluster of 4 UNI FANs via the cable module, allowing users to control up to 16 UNI FANs in one go. The L-Connect software enables users to control and adjust fan RPM, colors, brightness and lighting effects with extreme ease. moreover, pass control to the motherboard.
- DAISY-CHAIN DESIGN AN ENJOYABLE EXPERIENCE
- L-CONNECT INTUITIVE CONTROL INTERFACE
- MULTIPLES EFFECT/ABILITY TO SYNC 32 LEDS PER FAN
- HIGH STATIC PRESSURE QUIET OPERATION
- PREMIUM QUALITY SANDBLASTED ALUMINUM PARTS
- UNPRECEDENTED FLEXIBILITY A QUICKER AND EASIER INSTALLATION PROCESS
UNPRECEDENTED MODULARITY
• Slide-in / interlocking mechanism
• PIN-to-PIN contact point for receiving power and signal
• reduced need for mounting screws
DESIGNATED CABLE MODULES FOR UNI FAN
Each UNI FAN features a cable module with a PIN-to-PIN contact point to receive power and signal. Each cable module can support up to 4 UNI FAN, allowing users to choose to use either a single fan or up to 4 fans in one go.
SOPHISTICATED RGB LIGHTING
The 32 addressable RGB LEDs embedded in each fan (16 LEDs on either side of the frame) ensure vibrant lighting effects.
VIBRANT RGB LIGHTING VISIBLE FROM ALL ANGLES
The 16 LEDs on each side shine through a diffuser, ensuring a smooth light is visible from all angles.
L-CONNECT SOFTWARE FOR A MORE INTUITIVE FAN CONTROL
With the toggle of a switch, changing control between motherboard software and the L-Connect is a breeze.
MORE DURABLE, EXTREMELY SILENT
A close look at what makes UNI FAN operate efficiently.
PREMIUM LOOK, EXQUISITE DETAILING
- Machine-detailed aluminium frame
- Aluminium logo badge CD texture for an enhanced quality feel
A DESIGNATED UNI FAN CONTROLLER (UNI HUB)
TO EASILY MANAGE 16 FANS IN ONE GO

SPECIFICATIONS
| MODEL NAME | UNI FAN SL 140 | |
|---|---|---|
| Model NO. | UF-SL140-1B BLACK / UF-SL140-1W WHITE | |
| Fan Dimension | 140 X 140 X25 ( mm ) | |
| Fan Speed | 500~1500RPM | |
| Max. Air Pressure | 1.67mmH2O | |
| Max. Air Flow | 70.5 CFM | |
| Acoustical Noise (Min-Max.) | 30dB(A) Max | |
| Locked Current | >= 10mA | |
| Bearing Type | Fluid Dynamic Bearing (FDB) | |
| Connector Type (single pack) | 1 x 4 Pin (PWM) + 3 Pin (ARGB) | |
| Connector Type (3 pack / 2 pack) | 1 x 4 Pin (PWM) + 2 x SM 3 Pin (ARGB) | |
| Start-up Voltage | DC 6.0V | |
| Input Power | 3.6W | |
| Rated Voltage | DC 12V (FAN) / 5V (LED) | |
| Rated Current | 0.1A (FAN) / 0.34A (LED) | |
| Warranty | 2 year | |
