Seasonic

Seasonic Prime PX-2200 ATX 3.1 (2024) 80 Plus® Platinum Fully Modular Power Supply - Digital Hybrid Fan Control, ATX 3.1 & PCI-E Gen 5.1 (12 Year Warranty)

Seasonic Prime PX-2200 ATX 3.1 (2024) 80 Plus® Platinum Fully Modular Power Supply - Digital Hybrid Fan Control, ATX 3.1 & PCI-E Gen 5.1 (12 Year Warranty)

$869.00 SGD
$869.00 SGD
Sale Sold out

PRIME PX ATX 3.1

The Seasonic PRIME PX-2200 is a robust power supply capable of safely powering up to four RTX 4090 graphics cards, thanks to its adherence to ATX 3.1 and PCIe 5.1 specifications. Designed for demanding applications such as artificial intelligence and other high-power workloads, this flagship unit from the PRIME series delivers top-tier performance built on high-quality components.

  • 80 PLUS® PLATINUM - 92 % efficiency at 50 % system load
  • 12 Years Warranty
  • Fully Modular
  • ATX 3.1 & PCIe 5.1
  • Dimension: 210 mm (L) x 150 mm (W) x 86 mm (H)

ATX 3.1 and 16-Pin PCIe Gen 5.1 Cable (12V-2x6)

Seasonic’s latest PRIME ATX 3.1 Series is designed and built to power new PC components requiring the new ATX 3.1 and PCIe 5.1 standards.

Micro Tolerance Load Regulation

Seasonic’s latest design keeps the output voltage within a very tight range, achieving under 1 % load regulation. This impressive electrical performance and stability makes this power supply an ideal choice for high-performance systems.

Digital Hybrid Fan Control

Seasonic’s vast experience in designing the most silent and efficient power supplies on the market was translated into the development of Hybrid Mode; a state-of-the-art digital fan control that enables users to keep the overall fan noise at the lowest possible level.

  • Reduced noise without increase in temperature
  • Extended fan life due to the reduced number of fan rotations
  • Optimized heat dissipation at all times
  • Unsurpassed silent performance in Fanless Mode

Fluid Dynamic Fan Bearing

High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. Due to the effortless, quieter rotations and its robust construction, this reliable fan technology also greatly increases the lifespan of the fan.

Technical Specifications

80PLUS® Platinum
Cybenetics Efficiency Level Titanium
Cybenetics Noise Level Standard++
Form Factor ATX/EPS
Dimensions 210 × 150 × 86 mm
Fan Information Fan Size: 135 mm
Fan Control: Digital Hybrid Fan Control
Fan Bearing: Fluid Dynamic Bearing
Life Expectancy: 50,000 hours at 40 °C,
15 % - 65 % RH
Cable Information Modularity: Fully Modular
Cable type: Individual Black Cables with Braided Pattern
Electrical Features Operating Temperature: 0 - 50 °C
MTBF @ 25°C, excl. fan: 100,000 hours
AC Input: Fixed 230 V
Protection: OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC: cTUVus, TUV, CB, CCC, BSMI, EAC, CE
Environmental Compliance: Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 12 Years


Power Output

AC Input 200 V - 240 V
15 A
50 Hz - 60 Hz
DC Output Rail: +3.3 V +5 V +12 V -12 V +5 VSB
Maximum
Power:		 25 A 25 A 183.3 A 0.5 A 3 A
125 W 2200 W 6 W 15 W
Total continuous power: 2200W
