TECWARE VXM Mesh Dual Chamber MATX Case (White) - Mesh Front Panel / Side Tempered Glass Panel

VXM Mesh Dual Chamber MATX Case

Tempered Glass Display

Showcase your ultimate build in full view through the seamless tempered glass panels.

• Additional 2x Front Fan slots for the Mesh version.



Compact, yet Spacious

Much like the VXR, it accommodates multiple configurations but maintains a small footprint.

Motherboard Compatibility

❶ Micro-ATX (Standard): 9.6 x 9.6in *Extension Bracket req.
❷ Micro-ATX (Compact): 9.6 x 7.9in
❸ Mini-ITX: 6.7 x 6.7in

Tool-less Panel Design

• Featuring a locking mechanism that slides all panels in place without screws.
• Seamless and convenient.



SPECIFICATIONS

I/O:
• Super Speed USB 3.0 x 02
• HD Audio + Microphone Jack

BAYS:
• 1 x 3.5” HDD
• Up to 3 x 2.5” SSD
• 4 x PCI Expansion Slots

FANS:
• Top: 2 x 120mm
• Bottom: 2 x 120mm
• Side: 2 x 120mm
• Front: 2x  120mm (Mesh version only)

SUPPORT AND CLEARANCE:
• 320mm Max GPU Length
• 140mm Max CPU Cooler Height
• 160mm Max PSU Length
• mATX, ITX

RADIATOR CLEARANCE:
• Top: 120 / 240mm
• Bottom: 120 / 240mm
• Side: 120 / 240mm

OTHERS:
• Tool-less Panel Design
• Rubber Grommets Included

SIZE:
• Dimensions: (L)338 x (W)255 x (H)335mm
