Thermalright AXP90 X36 / X47 / X53 Low Profile ITX CPU Air Cooler - Low profile CPU cooler, Socket supported AMD and Intel

Thermalright AXP90 X36 / X47 / X53 Low Profile ITX CPU Air Cooler - Low profile CPU cooler, Socket supported AMD and Intel

$49.00 SGD
$49.00 SGD
Sale Sold out

Thermalright AXP90 X36 / X47 / X53

Dual Soldered Process
Both Nickle plated copper base and four high performance heat pipes are soldered with fins for maximum heat transfer and withstand usage over long period of time.

100% RAM and PCIe compatibility
Optimized heatsink design for compatibility for ITX motherboard, even the PCIe and RAM slots are close to CPU socket, AXP90-X low profile cooler is still compatible with high memory modules or thick PCIe cards.

Low profile height
Fits in most small form factor cases, while TL-9015 FAN fan is capable of generating airflow to cool heatsink and motherboard components.

Tech Specifications AXP90 X36

Intel: LGA115X / 1200 / 1700 / 1851    |    AMD: AM4 / AM5
Heatsink Specifications
Dimension: L94.5 mm x W95 mm x H21 mm
 Heat pipes: 6mm heatpipe x 4 units
Copper base: C1100 Pure Copper nickel plated Weight (With Fan): 230g
Fin: T = 0.3 mm；Gap = 1.6 mm
TL-9015 FAN Spec
Dimension: L92 mm x W92 mm x H15 mm
 Rated Speed: 2700 RPM±10% (MAX)
Noise Level: 22.4 dBA Air Flow: 42.58 CFM (MAX)
Air Pressure: 1.33mm H2O (MAX) Connector: 4 Pin (PWM Fan connector)
Ampere: 0.18 A Bearing Type: HYDRAULIC Bearing


Tech Specifications AXP90 X47

Intel: LGA115X / 1200 / 1700 / 1851    |    AMD: AM4 / AM5
Heatsink Specifications
Dimension: L94.5 mm x W95 mm x H32 mm
 Heat pipes: 6mm heatpipe x 4 units
Copper base: C1100 Pure Copper nickel plated Weight (With Fan): 310g
Fin: T = 0.3 mm；Gap = 1.6 mm
TL-9015 FAN Spec
Dimension: L92 mm x W92 mm x H15 mm
 Rated Speed: 2700 RPM±10% (MAX)
Noise Level: 22.4 dBA Air Flow: 42.58 CFM (MAX)
Air Pressure: 1.33mm H2O (MAX) Connector: 4 Pin (PWM Fan connector)
Ampere: 0.18 A Bearing Type: HYDRAULIC Bearing


Tech Specifications AXP90 X53

Intel: LGA115X / 1200 / 1700 / 1851    |    AMD: AM4 / AM5
Heatsink Specifications
Dimension: L94.5 mm x W95 mm x H38 mm
 Heat pipes: 6mm heatpipe x 4 units
Copper base: C1100 Pure Copper nickel plated Weight (With Fan): 320g
Fin: T = 0.3 mm；Gap = 1.6 mm
TL-9015 FAN Spec
Dimension: L92 mm x W92 mm x H15 mm
 Rated Speed: 2700 RPM±10% (MAX)
Noise Level: 22.4 dBA Air Flow: 42.58 CFM (MAX)
Air Pressure: 1.33mm H2O (MAX) Connector: 4 Pin (PWM Fan connector)
Ampere: 0.18 A Bearing Type: HYDRAULIC Bearing
